Pre-Amp: Low noise solid state
Instrument Input: ¼’ Phone with rotary gain control
Input Level Indicator: Signal level and Clip LEDs (green/red)
EQ: 4 Band (12dB Boost/Cut) with switchable Mid
Shelving Bass (80Hz) and Treble (4KHz / 8KHz selectable)
Low-Mid and Hi–Mid -Variable Gain, Band Pass EQ with selectable frequency/bandwidth options
Master Volume: Rotary Control
EQ On/Off Footswitch
Mute Footswitch
Tuner Out: ¼” Phone jack
Amp Out: ¼” Phone jack
Direct Out: 600 Ohm Balanced XLR, Pre/Post, and Ground Lift
Power Requirements: 12V DC (150mA minimum)
Power Consumption: 150mA
Chassis: Steel
Removable Rubber Feet: Adhesive backed
Size:
(H x W x D in.) 6.05 x 4.86 x 1.74
(H x W x D cm) 15.38 x 12.34 x 4.41
Weight: 1.93 lbs / .88 kg
