Pre-Amp: Low noise solid state
Mono/Dual Instrument Inputs: ¼’ Phone with rotary gain control
Input Level Indicator: Signal level and Clip LEDs (green/red)
Channel A EQ: 4 Band with switchable Mid
Shelving Bass and Treble
Low-Mid and Hi–Mid -Variable Gain, Band Pass EQ with selectable frequency/bandwidth options
Channel B EQ: 4 Band
Shelving Bass and Treble
Low-Mid and Hi–Mid -Variable Gain, Band Pass EQ
Master Volume: Rotary Control
Channel A/B Footswitch
FX On/Off Footswitch
Mute Footswitch
Line In: 1/8” mini jack
Headphone Out: Stereo 1/8” mini jack
Tuner Out: ¼” Phone jack
Amp Out: ¼” Phone jack
EFX Loop: Parallel with side-chain dry blend
Insert Loop: Series
Direct Out: 600 Ohm Balanced XLR, Pre/Post, and Ground Lift
AUX Out: 600 Ohm Balanced XLR, Post EQ
Power Requirements: 12V DC (250mA minimum)
Chassis: Aluminum
Removable Rubber Feet: Adhesive backed
Size:
(H x W x D in.) 1.54 front / 2.04 back x 8.50 x 6.03
(H x W x D cm) 3.93 front / 5.20 back x 21.59 x 15.33
Weight: 1.83 lbs / .83 kg
